VeEX Videomicroscope DI-1000MPO

Request a quote

VeEX Videomicroscope DI-1000MPO

Request for quote

The DI-1000MPO is optimized for testing MTP/MPO connectors retaining backwards compatibility with existing single fiber tips. The scanning and focus knobs are conveniently located on the microscope body providing simple and efficient handheld operation. The host device software performs visual inspection, image capture, and Pass/Fail results.

Main features of the product:

  • Precise and reliable single-finger focusing
  • X and Y scanning controls on Fiberscope body
  • Ergonomic design offering one hand operation
  • Robust for field use (no motors or batteries)
  • Inspect patch cords and bulkheads
  • Supports 12 up to 48 fiber MTP/MPO connector types
  • Large field of view (FOV) 425 x 320 μm
  • 1/3 inch CMOS sensor
  • Blue LED light source for end face illumination
  • Widest host platform compatibility in the industry
    – Select VeEX test platforms
    – Windows PC – Fiberizer™ Scope software
    – Mobile devices – Fiberizer™ software (Android & iOS)
  • USB or WiFi connection to tester, PC or mobile device
  • Powered by USB
  • Comprehensive range of single and multi-fiber tips, including PC and APC versions
  • Lightweight and compact
  • Quick tip replacement – MTP/MPO and single fiber
